Video
Beskrivelse
Detaljer
• 110W LED source
• 7 Rotating Gobos & 8 Colors
• 16 Built-in programs selectable by DMX
• Menu on Full color display
• Motorized focus
The Phantom 140 Spot is the ´middleman´ in our successful Phantom series. It has more output power compared to the Phantom 75, and is lighter and more compact compared to the Phantom 225. Equipped with beautiful full color display and professional finish. It houses a high efficient 110W LED source, high efficient optics for maximizing the output, 8 colors, 7 gobo´s, motorized focus, 3-facet prism, electronic dimmer and fast strobe.
• 7 Rotating Gobos & 8 Colors
• 16 Built-in programs selectable by DMX
• Menu on Full color display
• Motorized focus
The Phantom 140 Spot is the ´middleman´ in our successful Phantom series. It has more output power compared to the Phantom 75, and is lighter and more compact compared to the Phantom 225. Equipped with beautiful full color display and professional finish. It houses a high efficient 110W LED source, high efficient optics for maximizing the output, 8 colors, 7 gobo´s, motorized focus, 3-facet prism, electronic dimmer and fast strobe.
Specifikationer
Detaljer
• Output
• Light Source: 110W White LED
• Beam angle: 17°
• Electrical
• Input Voltage: 100-240 VAC
• Power consumption: 230W max. at full output
• Control
• On-Board: Full color display, Auto-, Sound control
• & Master/Slave mode
• Control Protocol: DMX512
• Control Personality: Advanced 14ch /Basic 8ch
• Optical system
• Dimmer: 0-100%
• Strobe: 0-20Hz
• Focus: Motorized
• Prism: 3-facet prism
• Movement
• Pan: 540°
• Tilt: 270°
• Pan/Tilt resolution: 16 bit
• Special: Pan / Tilt movement blackout,
• User-selectable Pan & Tilt ranges, 540°/360°/180°
• Reverse Pan / Tilt movement
• Gobos & Colors
• Gobowheel: 1 glass + 6 metal gobos (replaceable)
• Gobo functions: Gobo-flow effect,Gobo shake
• Rotation: Bi-directional
• Gobo inner diameter: 23 mm
• Gobo outer diameter: 27 mm
• Colors: 7 dichroic-filters + white
• Color functions: Split colors, Rainbow-flow effect
• Physical
• Color: Black
• Housing: Metal & Flame-retardant plastic
• Fixture Connection: XLR Data in/out, IEC Power in
• Dimensions (WxDxH): 320 x 245 x 465 mm
• Weight: 14 kg
• Certification and Safety
• Certification: CE
• Max. ambient Temp.: 40°C
• Light Source: 110W White LED
• Beam angle: 17°
• Electrical
• Input Voltage: 100-240 VAC
• Power consumption: 230W max. at full output
• Control
• On-Board: Full color display, Auto-, Sound control
• & Master/Slave mode
• Control Protocol: DMX512
• Control Personality: Advanced 14ch /Basic 8ch
• Optical system
• Dimmer: 0-100%
• Strobe: 0-20Hz
• Focus: Motorized
• Prism: 3-facet prism
• Movement
• Pan: 540°
• Tilt: 270°
• Pan/Tilt resolution: 16 bit
• Special: Pan / Tilt movement blackout,
• User-selectable Pan & Tilt ranges, 540°/360°/180°
• Reverse Pan / Tilt movement
• Gobos & Colors
• Gobowheel: 1 glass + 6 metal gobos (replaceable)
• Gobo functions: Gobo-flow effect,Gobo shake
• Rotation: Bi-directional
• Gobo inner diameter: 23 mm
• Gobo outer diameter: 27 mm
• Colors: 7 dichroic-filters + white
• Color functions: Split colors, Rainbow-flow effect
• Physical
• Color: Black
• Housing: Metal & Flame-retardant plastic
• Fixture Connection: XLR Data in/out, IEC Power in
• Dimensions (WxDxH): 320 x 245 x 465 mm
• Weight: 14 kg
• Certification and Safety
• Certification: CE
• Max. ambient Temp.: 40°C
