• Familiar keys, numeric keypad and 4 Encoders
• 10 Playback faders with Go, Pause/Reverse,
Flash keys on multiple pages
• 10 Executer/Flash keys on multiple pages
• Color picker, Swatchbook by Lee, Rosco
and Apollo Filters
• Gobo Picker
• User definable groups and presets
• User definable display layout
• 4 user definable master faders
• Effects engine
• Fan functions on all attributes
• Built in Fixture library and Fixture builder
• Cue list screen
• 4 x DMX 5-pin opto-isolated in/outs (RDM ready)
• Ethernet/Artnet
• HDMI monitor out
• Midi In/Thru/Out 5-pin DIN
• Audio/SMPTE/LTC Input 3-pin XLR
• IEC Power Supply Input
• 2 x Dimmable Desklight outputs 3-pin XLR
• 2 x USB-B connectors
• 4 universe 2048 channels DMX
• 300 Fixtures
• 10000 memories
• 400 memory stacks
• 100 groups
• 9 x 100 presets (position, color, beam,
effects, etc.)
• Command line interface
• Output visualizer
• Tracking and non-tracking options
• Display: 22 inch 1920x1080 Hull HD
• Touch: Digital resistive touch
• Dimensions: 647 x 575 x 279mm (LxWxH)
• Weight: 18Kg
• Ambient Temp. Range: 0 ~ 35°C
• Storage Temp. Range: -5 ~ 45°C
• 10 Playback faders with Go, Pause/Reverse,
Flash keys on multiple pages
• 10 Executer/Flash keys on multiple pages
• Color picker, Swatchbook by Lee, Rosco
and Apollo Filters
• Gobo Picker
• User definable groups and presets
• User definable display layout
• 4 user definable master faders
• Effects engine
• Fan functions on all attributes
• Built in Fixture library and Fixture builder
• Cue list screen
• 4 x DMX 5-pin opto-isolated in/outs (RDM ready)
• Ethernet/Artnet
• HDMI monitor out
• Midi In/Thru/Out 5-pin DIN
• Audio/SMPTE/LTC Input 3-pin XLR
• IEC Power Supply Input
• 2 x Dimmable Desklight outputs 3-pin XLR
• 2 x USB-B connectors
• 4 universe 2048 channels DMX
• 300 Fixtures
• 10000 memories
• 400 memory stacks
• 100 groups
• 9 x 100 presets (position, color, beam,
effects, etc.)
• Command line interface
• Output visualizer
• Tracking and non-tracking options
• Display: 22 inch 1920x1080 Hull HD
• Touch: Digital resistive touch
• Dimensions: 647 x 575 x 279mm (LxWxH)
• Weight: 18Kg
• Ambient Temp. Range: 0 ~ 35°C
• Storage Temp. Range: -5 ~ 45°C
